Seleco Walkie Mod. CD TV – 2A Boxed saved just in time from the junk.
Commodore Joystick 1342 donated from a friend.
Autopsy:
from Wikipedia:
The Enterprise is a Zilog Z80-based home computer first produced in 1985. It was developed by British company Intelligent Software and marketed by Enterprise Computers. Its two variants are the Enterprise 64, with 64 kilobytes (kB) of Random Access Memory (RAM), and the Enterprise 128, with 128 kB of RAM.
The Enterprise has a 4 megahertz (MHz) Z80 Central processing unit (CPU), 64 kB or 128 kB of RAM, and 32 kB of internal read-only memory (ROM) that contains the EXOS operating system and a screen editor / word processor. The BASIC programming language was supplied on a 16 kB ROM module.
Two application-specific integrated circuit (ASIC) chips take some of the workload off of the central processor. They are named “Nick” and “Dave” after their designers, Nick Toop, who had previously worked on the Acorn Atom, and Dave Woodfield. “Nick” manages graphics, while “Dave” handles sound and memory paging (bank switching).
A bank switching scheme allows the memory to be expanded to a maximum of 4 megabytes (MB). The highest 2 address lines from the Z80 are used to select one of the four 8-bit Page Registers in Dave chip. The output from the selected register is used as the highest 8 bits of the 22-bit address bus, while the lowest 14 bits come directly from the Z80 address bus. Effectively, the 64 kB address space of the Z80 processor is divided into four 16k sections. Any 16k page from the 4 MB address space can be mapped to any of these sections. The lowest two pages (pages 0 and 1) of the 4 MB address space contain system ROM.
The next four pages (2 to 5) are reserved for a ROM cartridge (max 64 kB). The top four pages (pages 252 to 255, totaling 64 kB) are used as video RAM, but can be used for storage of program code and data as well. On the 128k model, the additional 64 kB of ram is mapped on pages 248 to 251. The remaining memory space can be used by external devices and memory modules connected to the expansion bus.
Loading a demo from Tape:
Autopsy:
Thanks to Paolo Cognetti for giving me this device in good conditions.
Plug ‘n Power Programmable Appliance/Light Controller it’s an old device for the TRS-80 Color Computer for home automation.
Object consists of Plug ‘n Power, Appliance and Light Controller, two cords, a manual, and battery test card.
Download: Plug & Power Appliance and Light Controller (PDF) (2652)
Today a friend has donated to me some nice things. Thanks Damiano (Manosoft).
Things that have been donated:
Autopsy:
This configuration includes:
from Wikipedia:
Spectravideo, or SVI, was a U.S. computer company founded in 1981 as “SpectraVision” by Harry Fox. They originally made video games for Atari 2600 and VIC-20. Some of their computers were MSX-compliant or IBM PC compatible. They ceased operations in 1988.
SpectraVision was founded in 1981 by Harry Fox and Oscar Jutzeler as a distributor of computer games, contracting external developers to write the software. Their main products were gaming cartridges for the Atari 2600 VCS, Colecovision and Commodore VIC-20. They also made the world’s first ergonomic joystick, the Quickshot. In late 1982 the company was renamed to Spectravideo due to a naming conflict with OnCommand’s Hotel TV system called SpectraVision.
In the early 1980s, the company developed 11 games for the Atari 2600, including several titles of some rarity: Chase the Chuckwagon, Mangia and Bumper Bash. A few of their titles were only available through the Columbia House music club.
The company’s first attempt at a computer was an add-on for the Atari 2600 called the Spectravideo CompuMate, with a membrane keyboard and very simple programmability.
Their first real computers were the SV-318 and SV-328, released in 1983. Both were powered by a Z80 A at 3.6 MHz, but differed in the amount of RAM (SV-318 had 32KB and SV-328 had 80KB total, of which 16KB was reserved for video) and keyboard style. The main operating system, residing in ROM, was a version of Microsoft Extended Basic, but if the computer was equipped with a floppy drive, the user had the option to boot with CP/M instead. These two computers were precedent to MSX and not fully compatible with the standard, though the changes made to their design to create MSX were minor. The system had a wide range of optional hardware, for example an adapter making it possible to run ColecoVision games on the SVI.
A later version, the Spectravideo SVI-728 was made MSX compatible. SVI-738, also MSX compatible, came with a built-in 360 KB 3.5″ floppy drive. The last computer produced by Spectravideo was the SVI-838 (also known as Spectravideo X’Press 16). It was a PC and MSX2 in the same device.
Today the Spectravideo name is used by a UK based company called SpectraVideo Plc, formerly known as Ash & Newman. That company was founded in 1977, and bought the Spectravideo brand name from Bondwell (SVI owner) in 1988. They sell their own range of Logic3 branded products, and do not have any connection to the old Spectravideo products.
source: wikipedia
Autopsy:
from Roger Spectravideo homepage:
The SV-803 16K RAM Pack allows you to easily and economically add 16K worth of “Random Access Memory” to your SV computer. You can bank switch to a second bank of memory from BASIC.
Download: SVI 803-807 Users Manual (1206)
source: roger spectravideo homepage
Autopsy:
from Roger Spectravideo homepage:
SV-602 Single Slot Expander it houses one interface cartridge, and provides a very economical means of interfacing your SV computer with a single peripheral at a time.
source: roger spectravideo homepage
Autopsy:
from Roger Spectravideo homepage:
SV-904 Data Cassette it connect easily to the SV-318 or SV-328, our data cassette provides an inexpensive means of running and storing a wide range of computer programs.
source: roger spectravideo homepage
Autopsy:
from Wikipedia:
The Dragon 32 and Dragon 64 are home computers that were built in the 1980s. The Dragons are very similar to the TRS-80 Color Computer (CoCo), and were produced for the European market by Dragon Data, Ltd., in Port Talbot, Wales, and for the US market by Tano of New Orleans, Louisiana. The model numbers reflect the primary difference between the two machines, which have 32 and 64 kilobytes of RAM, respectively.
In the early 1980s, the British home computer market was booming. New machines were released almost monthly. In August 1982, Dragon Data joined the fray with the Dragon 32; the Dragon 64 followed a year later. The computers sold quite well initially and attracted the interest of several independent software developers, most notably Microdeal. A magazine, Dragon User also began publication shortly after the machine’s launch.
In the private home computer market, where games were a significant driver, the Dragon suffered due to its graphical capabilities, which were inferior to contemporary machines such as the Sinclair ZX Spectrum and BBC Micro.
The Dragon was also unable to display lower-case letters easily. Some more sophisticated applications would synthesise them using high-resolution graphics modes (in the same way that user-defined characters would be designed for purely graphical applications such as games). Simpler programs just managed without lower case. This effectively locked it out of the then-blooming educational market.
As a result of these limitations, the Dragon was not a commercial success, and Dragon Data collapsed in June 1984.
Video of Chuckie Egg game for Dragon 64:
source: wikipedia archive.worldofdragon.org
Autopsy:
from Wikipedia:
The Sega Pico, also known as Kids Computer Pico (キッズコンピューター・ピコ Kizzu Konpyūtā Piko?), is an electronic toy by Sega. The aim of creating the Pico was to get more young children (specifically, ages 2–8) to use video game systems. The Pico was the first Sega-branded console to carry an officially licensed game from former competitor Nintendo.
The Pico was released in 1993 in Japan and 1994 in North America and Europe. In Japan, the system was a huge success and games were developed until 2005. In North America and Europe, however, the Pico was less successful and games were only developed until 1997. The Pico was also released in South Korea, and it seems to be more successful unlike the west. To celebrate its 10th anniversary in 2003 in Japan, Sega re-released some of the Pico games. As of April 2005, 3.4 million Pico consoles and 11.2 million software cartridges had been sold.
The Sega Pico’s slogan was: “The computer that thinks it’s a toy.”
The ROM cartridges were called “Storyware,” and were book shaped. Each time a player turned the page of the cartridge the screen changed to replicate the image in the book. The games were controlled by a “magic” pen and buttons. The last page of each book features a freehand drawing mode, where the player can also insert stamps of characters shown previously in the game. All software released for the Pico received a rating from either the V.R.C. or the ESRB.
source: wikipedia
Autopsy:
from Wikipedia homepage:
The Timex Sinclair 1000 (TS1000) was the first computer produced by Timex Sinclair, a joint-venture between Timex Corporation and Sinclair Research. It was launched in July 1982.
The TS1000 was a slightly-modified Sinclair ZX81 with an NTSC RF modulator instead of a UK PAL (Units sold in Portugal have a PAL RF modulator) device and the onboard RAM doubled to 2K. The TS1000′s casing had slightly more internal shielding but remained the same as Sinclair’s, including the membrane keyboard. It had black-and-white graphics and no sound. It was followed by an improved version, the Timex Sinclair 1500.
Like the Sinclair ZX81, the TS1000 used a form of BASIC as its primary interface and programming language. To make the membrane keyboard less cumbersome for program entry, the TS1000 used a shortcut system of one-letter “keywords” for most commands (e.g. pressing “P” while the cursor was in “keyword mode” would generate the keyword “PRINT”). Some keywords required a short sequence of keystrokes (e.g. SHIFT-ENTER S would generate the keyword “LPRINT”). The TS1000 clued the user in on what to expect by changing the cursor to reflect the current input mode.
The TS1000 sold for $99.95 in the US when it debuted, making it the cheapest home computer to date at the time of its launch (its advertising angle was “the first computer under $100″.) This pricing initiated a price war with Commodore International, who quickly reduced the price of its VIC-20 to match and later announced a trade-in program offering $100 for any competing computer toward the purchase of a Commodore 64. Since the TS1000 was selling for $49 by this time, many customers bought them for the sole purpose of trading it in to Commodore.
source: wikipedia
Autopsy:
from AtariMuseum homepage:
In 1982 Atari’s Home Computer Division (HCD) introduced the new replacement computer to its aging Atari 400/800 line. The new computer brought to Atari’s home computers line a high-tech and sleek low profile modern look. The case design and the “XL Look” were created by Regan Cheng of Atari’s Industrial Design group. The all new design took the 7 separate boards that made up the Atari 800 (Main, Power, CPU, OS and 3 16K Memory boards) and integrated them into a single motherboard with 64K of memory. The system also brought with it probably “THE” best keyboard for any Atari system.
The system featured many new internal and external enhancements. Some of the obvious ones were the new Function keys and built-in HELP key that programmers could incorporate their usage into future programs. The tangle of wires from the system were now out of the back making for a clean and uncluttered arrangement. The cartridge port and controller jacks were now on the left side of the system. The new OS was designed for a new era of SIO “Plug n Play” devices to automatically load their device drivers and even on-board applications right into the 1200XL memory, also an International Character Set and built-in Diagnostic features were now part of the system. Other OS enhancements were included as well.
However the downside was that many programs by both 3rd party companies and even Atari itself were incompatible with this new OS in the machine. The loss of 2 of the 4 original controller jacks from the earlier Atari 400/800 systems didn’t seem like much of a big deal to the 1200XL engineers, however the end users did seem to mind. The system was supposed to have a better video display output signal, however to most end users, the system appeared to have a fuzzier display then the Atari 800. The true sticking point for consumers: No expansion whatsoever. While the idea of a “Closed Box” design seemed like a good idea to Atari’s Marketing Department, the consumer felt exactly the opposite.
Atari’s whole design philosophy for their home computer line was that these would be Consumer Oriented, not Hobbyist Oriented Systems. Therefore that meant buffering the user from the actual electronics and chips within the machines. This design was very well executed on the Atari 800 with its easy to remove top cover and its various OS and Memory modules fitted into easy to install packages. The SIO connector also gave users a universal, easy to handle and understand expansion system. Atari felt it could take this philosophy to the extreme with the 1200XL and completely cut the users off from ANY internal access. Even the simplest of users still wanted to tinker and expand their systems and the 1200XL just didn’t give them the flexibility found in Apple ][e’s, C64s or Atari’s original 800 line of computers. The collective shortcomings of the 1200XL unfortunately overshadowed its many new enhancements. Atari’s new prodigy became its “Edsil” The introduction of the new 1200XL actually increased sales of the Atari 800. Users began to buy 800′s in fear that they would be stuck with a closed and incompatible system.
Atari 1200XL Video:
source: atarimuseum.com
Autopsy:
The collection includes:
from Wikipedia homepage:
Aquarius is a home computer designed by Radofin and released by Mattel in 1983. It features a Zilog Z80 microprocessor, a rubber chiclet keyboard, 4K of RAM, and a subset of Microsoft BASIC in ROM. It connects to a television set and uses a cassette tape recorder for secondary data storage. A limited number of peripherals, such as a 40-column thermal printer, a 4-color printer/plotter, and a 300 baud modem, were released for the unit.
Looking to compete in the standalone computer market, Mattel Electronics turned to Radofin, the Hong Kong based manufacturer of their Intellivision consoles. Radofin had designed two computer systems. Internally they were known as “Checkers”, and the more sophisticated “Chess”. Mattel contracted for these to become the Aquarius and Aquarius II, respectively. Aquarius was announced in 1982 and finally released in June 1983, at a price of $160.
Production ceased four months later because of poor sales. Mattel paid Radofin to take back the marketing rights, and four other companies—CEZAR Industries, CRIMAC Inc., New Era Incentives, Inc., and Bentley Industries—also marketed the unit and accessories for it. Bentley Industries (of Los Angeles) and New Era Incentives, Inc. (of St. Paul) are still in business, though they no longer have any affiliation with the Aquarius product line.
source: wikipedia
Autopsy:
The photos of the inside can be found here.
from Wikipedia homepage:
The ZX81, released in a slightly modified form in the United States as the Timex Sinclair 1000, was a home computer produced by Sinclair Research and manufactured in Scotland by Timex Corporation. It was launched in the United Kingdom in March 1981 as the successor to Sinclair’s ZX80 and was designed to be a low-cost introduction to home computing for the general public. It was hugely successful and more than 1.5 million units were sold before it was eventually discontinued.
The ZX81 found commercial success in many other countries, notably the United States, where Timex manufactured and distributed it under licence and enjoyed a substantial but brief boom in sales. Timex later produced its own versions of the ZX81 for the US market – the Timex Sinclair 1000 and Timex Sinclair 1500. Unauthorised clones of the ZX81 were produced in a number of countries.
The ZX81 was designed to be small, simple, and above all cheap, using as few components as possible to keep the cost down. Video output was to a television set rather than a dedicated monitor. Programs and data were loaded and saved onto audio tape cassettes. It had only four silicon chips on board and a mere 1 kB of memory. The machine had no moving parts – not even a power switch – and used a touch-sensitive membrane keyboard for manual input.
The ZX81′s limitations prompted the emergence of a flourishing market in third-party peripherals to improve its capabilities. Such limitations, however, achieved Sinclair’s objective of keeping the cost of the machine as low as possible. Its distinctive design brought its designer, Rick Dickinson, a Design Council award.
The ZX81 could be bought by mail order in kit form or pre-assembled. In what was then a major innovation, it was the first cheap mass-market home computer that could be bought from high street stores, led by W.H. Smith and soon many other retailers. The ZX81 marked the first time that computing in Britain became an activity for the general public, rather than the preserve of businesspeople and electronics hobbyists. It inspired the creation of a huge community of enthusiasts, some of whom founded their own businesses producing software and hardware for the ZX81. Many went on to play a major role in the British computer industry in later years.
The ZX81′s commercial success made Sinclair Research one of Britain’s leading computer manufacturers and earned a fortune and an eventual knighthood for the company’s founder, Sir Clive Sinclair.
source: wikipedia
